Model 7357
Process Multimeter, 50.000 counts, TRMS AC+DC with current source and loop power
1 yr Warranty
No distributors seem to have what you're looking for in stock. You can try searching again with a different part number or visit our
Overview
Multimeter
- Voltage measuremet up to 1000V TRMS AC+DC and 1000V DC
- Basic accuracy: 0,05%
- Current measurement up to 1A
- Frequency measurement
- Resistance measurement up to 50 Mohms
- Continuity test with buzzer
- Diode test
- Digital filter (low-pass)
Process calibrator
- Current source: 4-20mA or 0-20mA
- Modes: steps, pre-defined values, user defined values
- Manual ot automatic current slopes
- Simulator mode (energy supplied by application)
- Power loop mode, with HART capability (250 ohms serial resistor)
General features
- 100 mesurements memory
- MIN/MAX/AVG, REL, Auto-HOLD functions
- USB (opto isolated) interface
- Panoramic LCD, with auto-backlight
- PC application software supplied
- Safety: 600V CAT IV and 1000V CAT III
Accessories
Straight fixed banana plug test leads (4mm)
SA100
- 4mm test probe
- Length: 1m
- Max current: 12A
- Set of 1 red and 1 black
- Safety: CAT III - 1000V and CAT IV - 600V
- MSRP: $
Right angle banana plug test lead set (4mm)
SA101
- 4mm test probe
- Length: 1m
- Max current: 12A
- Set of 1 red and 1 black
- Safety: CAT III - 1000V and CAT IV - 600V
- MSRP: $
Straight fixed banana plug test leads (2mm tip)
SA150
- 1.2m length
- 2mm test probe
- 4mm safety banana plug (instrument side)
- PVC cable
- Max current: 12A
- Set of 1 black, 1 red
- Safety: 1000V CAT IV according to new IEC61010-031:2008
- MSRP: $
IP2X test leads set with right angle safety banana
SA158
- IP2X test probes with 4mm tips
- Length: 1.2m
- PVC cable
- Max current: 12A
- Test probes with retractable and lockable sleeves
- Set of 1 red, 1 black
- Safety: 600V CAT IV and 1000V CAT III according to new IEC61010-031:2008
- MSRP: $
Replacement Analog Remote Control Connector
RMTCTLCNTR
Replacement Analog Remote Control Connector.
- For models:
- 1685B Series
- 1900B Series
- 9103 9104 Series
- MSRP: $20
16-channel isolated logic box
917008000
- 16 isolated logical channels (250V)
- Direct connection to the data recorder
- Compatible with all B&K data recorders
- Power supply for external sensor
- 3 Alarms (output)
- Input with safety bananas or fast connectors
- Supplied with interface cable and fast connectors
- Enables conversion of a AC voltage (for example 120 V, 50 Hz) into a logic HIGH signal
- Provides power supplies for external accessories such as sensors: 3.3V, 5V or 12V.
- MSRP: $1355
Rackmount kit for DAQ3120
RKDAQ
RKDAQ is a rackmount kit for the DAQ3120
- The kit holds up to two DAQ3120 systems
- 2U in size and fits in a standard 19” rack
- MSRP: $335
Connecting cable with bananas (female)
902407100
This cable is designed to connect a DAS220 or DAS240 input (channel) to your application.
It is fitted with 4mm (female) banana-type safety connectors for easy connection to your application.
Supplied in packs of 10.
- MSRP: $168
- MSRP: $47
Active test probe for MW9090 and MW9091
9090PROBE
Replacement active probe for MW9090 and MW9091 insulation controllers, with integrated test button for triggering measurement without pressing the device.
- MSRP: $
- MSRP: $
- MSRP: $
- MSRP: $
- MSRP: $
- MSRP: $
Capteur de courant mini Flex 30-300-3000A pour analyseurs d'énergie (boucle 48cm)
A1502
Pince ampèremétrique flexible monophasée (bobine de Rogowski) avec trois plages de mesure sélectionnables (longueur du capteur : 48 cm, diamètre maximal du conducteur : 14 cm). Ne nécessite pas d'alimentation externe, car elle est alimentée par l'instrument de mesure.
- MSRP: $
